| Parameter | Value / Range |
|---|---|
| Code | SH-200 |
| Shearing width | 140-230mm |
| Feeding speed | 60m/min |
| Shearing length | 300-3000mm |
| Shearing length precision | ±0.5mm |
| Shearing angle | 90° |
| Shearing angle precision | ±0.025 |
| Shearing thickness | Each layer 0.023mm, Max 15 layers |
| Stacking thickness | 180mm |
| Stacking position error | ±0.5mm |
| Length of the loading platform | 2000mm |
| Coil outer diameter | φ1100mm |
| Coil inner diameter | φ400mm |
Ensures minimal shearing error, effectively preserving the unique magnetic properties of amorphous alloys—critical for high-performance transformer/motor cores.
Equipped with CNC control and automatic functions, it reduces manual intervention, significantly accelerating processing speed and overall production efficiency.
Handles diverse amorphous alloy core specifications, meeting customized processing needs for different power/electrical equipment components.
Built with durable parts, it supports long-term consistent operation, lowering maintenance frequency and ensuring stable output quality.
Precisely shears amorphous alloy cores (with minimal error) to make transformer cores, reducing magnetic loss—ideal for energy-saving power transformers in grid construction.
Processes customized amorphous alloy core specs, supporting the fabrication of high-efficiency motors for new energy vehicles, industrial drives, and household appliances.
Adapts to diverse core sizes, providing accurately sheared amorphous alloy cores for low-loss reactors (used in power distribution) and inductors (for electronic equipment).
Supplies stable-quality amorphous alloy cores for special devices like UPS power supplies and energy storage systems, ensuring their reliable operation in power-sensitive scenarios.
The SH-200 offers exceptional precision with a shearing length error limit of within ±0.5mm and a shearing angle precision of ±0.025 degrees at a 90° angle.
The machine supports shearing a maximum of 15 layers of amorphous alloy simultaneously, with each layer measuring approximately 0.023mm in thickness.
Equipped with highly automated CNC controls, the SH-200 supports a feeding speed of up to 60m/min, significantly enhancing efficiency and minimizing manual labor.
It accommodates amorphous alloy coils with an outer diameter up to φ1100mm and an inner diameter of φ400mm, adapting smoothly to standard raw materials.
Amorphous alloys are highly sensitive to mechanical stress. The exceptional precision of the SH-200 preserves the material's magnetic integrity, ensuring minimal core loss for final products like transformers and motors.
The accurately sheared cores are primarily used in low-loss power distribution transformers, high-efficiency motors (for industrial and EV applications), low-loss reactors, and specialized electrical equipment.
