Introducing the Double-layer Foil Winding Machine, an advanced solution designed for synchronous double-layer foil coil winding, perfect for medium to low-voltage transformers, reactors, and power equipment. Manufactured by leading suppliers in China, this machine offers dual-path precise tension control, ensuring uniform layer distribution and automatic feeding for high-quality coils, Ideal for a variety of metal foils, the Double-layer Foil Winding Machine significantly enhances operational efficiency while minimizing manual labor. Its sophisticated design is widely utilized in the power and new energy sectors, making it a crucial asset for factories aiming to increase production efficiency and consistency. This machine is essential for meeting high manufacturing standards in today’s competitive market
Synchronous Double-layer Winding
Realizes simultaneous double-layer coil winding, reducing production steps and improving efficiency.
2
Dual-path Precision Control
Independent tension control for two foil paths, ensuring uniform layer distribution and coil accuracy.
3
High Production Efficiency
Automatic feeding & winding, cutting manual intervention and shortening the whole production cycle.
4
Wide Material Adaptability
Compatible with various metal foils (copper, aluminum) of different thicknesses for diverse needs.
5
Stable & Reliable Performance
Rigid structure and advanced control system, ensuring long-term stable operation and low failure rate.
Product Display
Application
1
Medium/High-Voltage Transformer Manufacturing
Core equipment for winding double-layer foil coils in medium/high-voltage power transformers, enhancing coil compactness.
2
Large-Capacity Reactor Production
Applied to wind double-layer foil coils for shunt reactors and filter reactors, meeting high-current requirements.
3
New Energy Power Conversion Systems
Suitable for coil manufacturing in new energy inverters, energy storage converters, and high-power rectifiers.
4
Industrial High-Power Equipment
Used in coil production for industrial frequency converters, high-power transformers, and welding power sources.
5
Railway Electrical Systems
Applied to winding coils for railway traction transformers and auxiliary power supply devices.
Frequently Asked Questions
Q
What foil materials are compatible with this double-layer foil winding machine?
The machine is compatible with both copper (Cu) and aluminum (Al) foils. Copper foil thickness ranges from 0.3–2.5mm, while aluminum foil thickness ranges from 0.5–3.0mm, making it suitable for a wide range of transformer and reactor manufacturing requirements.
Q
What are the available model options and their key differences?
Four models are available: SH-600, SH-800, SH-1100, and SH-1400. The primary differences lie in foil width capacity (600mm up to 1400mm), coil outer diameter range, and maximum foil tension (6,000N to 14,000N), allowing customers to select the best fit for their production scale.
Q
What welding methods does the machine support?
The machine supports two welding methods: TIG (Tungsten Inert Gas) welding and cold pressure welding. Both methods ensure strong, reliable joints suitable for high-performance coil applications.
Q
Can the machine wind both single-layer and double-layer coils?
Yes. The machine supports both single-layer and double-layer foil winding modes. The synchronous double-layer winding capability is one of its core features, enabling simultaneous production of two layers to significantly improve manufacturing efficiency.
Q
What industries or applications is this foil winding machine best suited for?
This machine is widely used in medium/high-voltage transformer manufacturing, large-capacity reactor production, new energy power conversion systems (inverters, energy storage), industrial high-power equipment, and railway electrical systems including traction transformers.
Q
How precise is the edge correction system on this machine?
The machine features an automatic edge correction system with a precision of ±0.5mm, ensuring consistent foil alignment throughout the winding process. This precision control is critical for producing high-quality coils with uniform layer distribution.
